The Molex 0534081209 is a 120-position plug connector designed for board-to-board and mezzanine applications. It features center strip contacts arranged in 2 rows with a 1.00mm pitch. The connector is surface mount and has a height above board of 16.35mm, with a mated stacking height of 18mm. Contacts are gold plated with a thickness of 10.0µin. The connector includes board guide and solder retention features to aid in alignment and secure mounting. This connector is part of Molex's array of board-to-board solutions, suitable for high-density interconnections in compact electronic assemblies. The 120 positions allow for high signal density, while the 1.00mm pitch enables space-saving designs. The surface mount package is compatible with standard SMT assembly processes. The gold contact finish ensures reliable electrical performance and corrosion resistance.
| Qty | Low | High |
|---|---|---|
| 1+ | $12.84 | $12.84 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
120 positions arranged in 2 rows.
1.00mm (0.039 inches).
Surface mount.
Gold with 10.0µin thickness.
18mm.
Board guide and solder retention.
