| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
439 pcs
|
439 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Body Material | |
| Contact Finish | |
| Contact Material | |
| Current Rating (Amps) | |
| For Use With | |
| Fuse Size | |
| Fuse Type | |
| Fuseholder Type | |
| Insulation Resistance | |
| Mounting Type | |
| Number of Circuits | |
| Operating Temperature | |
| Orientation | |
| SVHC Present | |
| Tape & Reel | |
| Termination Style | |
| Voltage | |
| Voltage Rating |
The Littelfuse 04820007ZXB is a 482 Series PCB mount blade fuseholder designed for use with Littelfuse 481 Alarm Indicating Fuses. It is rated for 15 amperes at 125V AC/DC and features a through-hole mounting style with PC pin termination.
This fuseholder accommodates blade-type fuses with dimensions 16.9mm x 8mm x 19.6mm and provides 7 independent circuits. The body is constructed from thermoplastic material rated UL 94V-0, and the contacts are made of tin-plated beryllium copper. The operating temperature range is -55°C to +125°C.
Ideal for telecommunications and control panel circuits, the 482 Series fuseholder is keyed to prevent insertion of 20A fuses. The vertical orientation and compact design facilitate dense PCB layouts.
The 04820007ZXB is rated for 15 amperes.
It is rated for 125V AC/DC.
It accepts blade-type fuses, specifically the Littelfuse 481 Alarm Fuse.
It provides 7 circuits.
It is a through-hole PCB mount with PC pin termination.
The operating temperature range is -55°C to +125°C.
The body is made of thermoplastic rated UL 94V-0.
