| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
180 pcs
|
180 pcs | On Request | 1 | On Request | On Request | N/A | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Current Rating (Amps) | |
| Fastening Type | |
| Features | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Lead Spacing | |
| Lead Style | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Operating Temperature | |
| Pitch | |
| Row Spacing | |
| Shrouding | |
| Style | |
| Tape & Reel | |
| Termination | |
| Termination Style | |
| Voltage Rating |
The Molex 0430450615 is a 6-position, 2-row, 3.00mm pitch surface mount header designed for board-to-cable/wire applications. It features a shrouded 4-wall design with a locking ramp for secure mating and a board lock for reliable PCB retention. The contacts are made of brass with a tin finish (60.0µin / 1.52µm) and are square in shape. The insulation is black liquid crystal polymer (LCP) glass filled, rated UL94 V-0. The header is rated for 8A current and 600V voltage, with an operating temperature range of -40°C to 105°C. Termination is via solder, and the component is surface mount compatible.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.13 | $3.13 |
| 10+ | $2.66 | $2.66 |
| 100+ | $2.26 | $2.26 |
| 200+ | $2.40 | $2.40 |
| 400+ | $2.28 | $2.28 |
| 600+ | $2.22 | $2.22 |
| 1,000+ | $2.14 | $2.14 |
| 1,400+ | $2.09 | $2.09 |
| 2,000+ | $2.04 | $2.04 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
6 positions.
3.00mm.
8A.
600V.
Surface mount.
-40°C to 105°C.
Liquid Crystal Polymer (LCP), glass filled.
