Mfr Part #:

0426240325

Name: 0426240325
Brand: Molex
SKU: 0426240325

Mfr Name: Molex

CONN HEADER R/A 15POS 2.54MM

Stock on Request

0426240325 Description

Short technical summary and product information.

CONN HEADER R/A 15POS 2.54MM

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

Same form/fit/function or matching attribute configuration across different manufacturers.

0022282154

Molex

CONN HEADER R/A 15POS 2.54MM

Category	Headers, Male Pins
Manufacturer Name	Molex
Connector Type	Header, Breakaway
Contact Finish	Tin
Contact Finish Thickness	100.0Âµin (2.54Âµm)
Contact Length	0.135" (3.43mm)
Contact Shape	Square
Contact Type	Male Pin
Fastening Type	Push-Pull
Insulation Color	Black
Insulation Height	0.284" (7.21mm)
Insulation Material	Polyamide (PA), Nylon, Glass Filled
Material Flammability Rating	UL94 V-0
Mounting Type	Through Hole, Right Angle
Number of Positions	15
Number of Positions Loaded	All
Number of Rows	1
Pitch	0.100" (2.54mm)
Shrouding	Shrouded - 1 Wall
Style	Board to Board or Cable
Termination	Kinked Pin, Solder
