| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
845 pcs
|
845 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Current Rating | |
| Current Saturation | |
| DC Resistance | |
| Inductance | |
| Lead Style | |
| Mounting Type | |
| Operating Temperature | |
| SVHC Present | |
| Self Resonant Frequency | |
| Tolerance |
The Coilcraft XGL1313-682MED is a high-performance shielded molded inductor designed for demanding applications. It offers an inductance value of 6.8 µH with a tolerance of ±20% and a significant current rating of 31 A. The DC resistance is kept low at a maximum of 4.3 mOhm, contributing to efficient operation.
This inductor is constructed with a metal composite core and features shielding for reduced electromagnetic interference. It operates within a temperature range of -40°C to 125°C. The component is designed for surface mounting and comes in Tape & Reel packaging, making it suitable for automated assembly processes.
With its robust specifications, including a saturation current of 26.5A and a self-resonant frequency of 13MHz, the XGL1313-682MED is well-suited for power supply circuits, filtering, and other electronic applications requiring reliable inductive components.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.20 | $0.20 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The inductance value is 6.8 µH.
The current rating is 31 A.
The maximum DC resistance is 4.3 mOhm.
The self-resonant frequency is 13 MHz.
It is supplied in a 2-SMD package, suitable for surface mounting and provided in Tape & Reel packaging.
