Mfr Part #:

0337900.PX2S

The Littelfuse 0337900.PX2S is a shunt fuse designed for 32V DC circuits. It offers a high interrupting rating and operates across a wide temperature range.

Stock on Request

0337900.PX2S Specifications Quick View

Most important parameters for selection – full specs in datasheet.

SELECT ALL

Category	Accessories
Manufacturer Name	Littelfuse Inc.
Accessory Type	Shunt
Current Rating	20 A
For Use With	MICRO3®
SVHC Present	Not Present
Voltage Rating	32 V DC

View Similar Products (0)

0337900.PX2S Description

Short technical summary and product information.

The Littelfuse 0337900.PX2S is a shunt-type accessory for MICRO3® fuses, designed to provide circuit protection in automotive and other high-current applications. It features a female terminal design that contributes to increased time delay and low voltage drop, making it suitable for protecting high current circuits and handling inrush currents.

This fuse operates at a voltage rating of 32V DC and has a significant interrupting rating of 1000A at 32V DC. The housing is constructed from PA66-GF13 material with a UL 94 HB flammability rating, and the cover is made of PC, also with a UL 94 HB rating. It is designed to operate within a wide environmental temperature range of -40°C to +125°C.

Key specifications include a typical voltage drop of 106mV and a typical cold resistance of 4.29mΩ for the 20A version. The fuse complies with SAE 27 41 and ISO 8820-4 standards. Its compact design and robust construction make it suitable for various automotive and off-road vehicle applications.

0337900.PX2S Quick Information

Product Type: Fuse Shunt

Series: MICRO3

Canonical Name: Littelfuse Inc. 0337900.PX2S Shunt Fuse

Subcategory: Shunt

0337900.PX2S Compliance

RoHS Status: RoHS Compliant

Moisture Sensitivity Level (MSL): 1 Unlimited

REACH Status: REACH Unaffected

0337900.PX2S Features

Rated for 32V DC operation.
High interrupting rating of 1000A.
Wide operating temperature range.
Durable PA66-GF13 housing material.
Complies with SAE 27 41 and ISO 8820-4.

0337900.PX2S Applications

Protects high current circuits.
Handles significant inrush currents.
Suitable for automotive applications.
Used in off-road vehicles.
Designed for watercraft applications.

0337900.PX2S FAQs

7 frequently asked questions generated from this part’s specifications.

What is the voltage rating of the 0337900.PX2S?

32V DC.

What is the current rating of the 0337900.PX2S?

20A.

What is the interrupting rating of the 0337900.PX2S?

1000A at 32V DC.

What is the operating temperature range of this shunt?

-40°C to +125°C.

What standards does the 0337900.PX2S comply with?

SAE 2741 and ISO 8820-4.

What is the housing material of the 0337900.PX2S?

PA66-GF13.

What is the packaging type for this part?

Bulk.
