| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
1,506,667 pcs
|
1506667 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Mounting Type | |
| Operating Temperature | |
| Power Dissipation | |
| Reverse Current |
The Toshiba 02CZ6.8-Z is a single, unidirectional Zener diode suitable for constant voltage regulation and reference voltage applications. It offers a nominal reference voltage of 6.8V with a maximum tolerance of 2.5% at a working test current of 5 mA.
This device has a maximum reverse current of 0.5 μA and a maximum knee impedance of 150 Ω. The maximum power dissipation is rated at 0.2 W. It operates within a temperature range of -55°C to +150°C and has a peak reflow temperature of 240°C.
The 02CZ6.8-Z comes in a surface-mount small outline package with gull wing terminals and a tin lead finish. Its rectangular package shape is designed for efficient integration into various electronic circuits.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.99 | $0.99 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The nominal Zener voltage is 6.8V at a working test current of 5mA.
The maximum voltage tolerance is ±2.5%.
The maximum power dissipation is 0.2W.
The maximum reverse current is 0.5μA at the working test current of 5mA.
The package is a Small Outline surface mount type with Gull Wing terminals.
The maximum operating temperature is 150°C.
The maximum peak reflow temperature is 240°C.
