| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Automotive Grade | |
| Color | |
| Current Rating | |
| Current Rating (Amps) | |
| Flammability Rating | |
| Fuse Type | |
| Height | |
| Housing Material | |
| Interrupting Rating | |
| Length | |
| Melting I²t | |
| Mounting Type | |
| Operating Temperature | |
| Package / Case | |
| Tape & Reel | |
| Terminal Material | |
| Termination Style | |
| Typical Cold Resistance | |
| Typical Voltage Drop | |
| Voltage Rating | |
| Weight | |
| Width |
The Littelfuse 0287025.PXCN is an ATOF series automotive blade fuse designed for low-voltage circuit protection in vehicles. It is rated at 25 A and 32 V DC, with an interrupting rating of 1000 A at 32 V DC. The fuse has a clear housing that allows visual inspection of the fuse element, and the amperage rating is indicated by the clear color per ATOF color code.
Key electrical specifications include a typical voltage drop of 92 mV at rated current and a cold resistance of 2.52 mΩ. The melting I²t is 1000 A²s. The operating temperature range is -40°C to +125°C. The fuse is housed in a PA66 plastic body with a UL 94 V-2 flammability rating, and the terminals are tin-plated.
This fuse requires a holder for mounting and uses the standard ATO/ATC blade package. It is suitable for use in cars, SUVs, trucks, buses, and watercraft. The fuse complies with SAE J1284 and ISO 8820-3 standards, and is UL listed and CSA certified.
The 0287025.PXCN variant is tin-plated and comes in a package quantity of 2000 pieces per reel or box, as indicated by the PXCN suffix in the ordering information.
The current rating is 25 A.
The voltage rating is 32 V DC.
The interrupting rating is 1000 A at 32 V DC.
It uses a blade package, ATO/ATC type.
The operating temperature range is -40°C to +125°C.
The clear color indicates a 25 A rating per the ATOF color code.
It is approved by CSA, UL, ISO 8820-3, and SAE J1284.
