| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
896 pcs
|
896 pcs | On Request | 1 | On Request | On Request | 6/20/2022 | On Request | On Request | |
|
340 pcs
|
340 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
3 pcs
|
3 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Approval Agency | |
| Breaking Capacity | |
| Breaking Capacity (32 VDC) | |
| Breaking Capacity @ Rated Voltage | |
| Cold Resistance | |
| Current Rating | |
| Current Rating (Amps) | |
| Fuse Type | |
| Halogen Free | |
| Height | |
| Length | |
| Melting I²t | |
| Mounting Type | |
| Operating Temperature | |
| Response Time | |
| SVHC Present | |
| Tape & Reel | |
| Termination Style | |
| Voltage Rating | |
| Width |
The Littelfuse 0157001.DR is a 1A, 125V fast blow board mount fuse from the 157 Series. It is designed for surface mount applications using a 2-SMD square end block with clip package, allowing easy replacement without desoldering.
Key electrical specifications include a current rating of 1A, voltage rating of 125V AC/DC, and a breaking capacity of 50A at 125V (300A at 32VDC). The fuse has a fast blow response time and a cold resistance of 0.0776 ohms. The melting I²t is 0.6029 A²s.
This fuse is suitable for overcurrent protection in instrumentation, base stations, and telecommunications equipment. It is RoHS compliant and halogen free, with operating temperature range of -55°C to 125°C.
The package dimensions are 6.50mm x 3.70mm x 3.90mm. Mounting requires a holder and surface mount clip.
1 A.
125 V AC/DC.
50 A at 125 VAC/VDC, 300 A at 32 VDC.
Fast blow (very fast-acting).
2-SMD, square end block with clip.
Yes, RoHS3 compliant and halogen free.
-55°C to 125°C.
