| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
3,948 pcs
|
3948 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
3,832 pcs
|
3832 pcs | On Request | 1 | On Request | On Request | 14+ | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Contact Finish | |
| Contact Material | |
| Current Rating (Amps) | |
| For Use With | |
| Fuse Size | |
| Fuse Type | |
| Fuseholder Type | |
| Max Current Rating | |
| Max Voltage Rating | |
| Mounting Type | |
| Number of Circuits | |
| Tape & Reel | |
| Termination Style | |
| Voltage | |
| Wire Gauge |
The Littelfuse 01550430ZXU is a panel mount blade fuse holder from the ATO 155 series, designed for 30A maximum current at 32V maximum voltage. It accepts ATC and ATO blade fuses, available separately.
This holder features a panel mount design with orange 10 AWG looped wire leads for termination. The contacts are made of brass with a tin finish. The fuse size accommodated is 0.75" L x 0.2" W (19.1mm x 5.1mm).
The stackable body allows multiple holders to be combined into a single fuse block for multi-circuit protection. Typical applications include automotive, electronics, and small auxiliary circuit protection. The holder is rated for use with fuses up to 30A when using the 10 AWG leads.
| Qty | Low | High |
|---|---|---|
| 1+ | $3.39 | $3.39 |
| 10+ | $3.27 | $3.27 |
| 50+ | $3.11 | $3.11 |
| 100+ | $2.99 | $2.99 |
| 250+ | $2.69 | $2.69 |
| 500+ | $2.48 | $2.48 |
| 1,500+ | $2.10 | $2.10 |
| 3,000+ | $2.09 | $2.09 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
The current rating is 30 A.
The voltage rating is 32 V.
It accepts blade type fuses, specifically ATC and ATO styles.
It is a panel mount fuse holder.
It has wire leads termination, specifically orange 10 AWG looped wire leads.
Yes, it is stackable allowing multiple holders to be combined into a fuse block.
The fuse size is 0.75" L x 0.2" W (19.1mm x 5.1mm).
