01-131.025 The EAO 01-131.025 is a pushbutton switch with a DPST-NO/NC circuit, rated for 5A at 250V. It features solder lug termination and IP40 ingress protection.
Mfr Part #:

01-131.025

Available from 1 distributors
Mfr Name: EAO
EAO
The EAO 01-131.025 is a pushbutton switch with a DPST-NO/NC circuit, rated for 5A at 250V. It features solder lug termination and IP40 ingress protection.
Stock on Request
$ Price Range: $0.75

01-131.025 Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Fe Components ✓
Non-Authorised Inventory information
On Request
On Request
On Request On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

01-131.025 Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Actuator Marking
Actuator Type
Circuit
Contacts
Current Rating (Amps)
Failure Rate
Ingress Protection
Lens Material
Mounting Type
Operating Temperature
Panel Cutout Dimensions
Ratings
Switch Function
Terminal
Termination Style
Type
Voltage Rating
View Similar Products (0)

01-131.025 Description

Short technical summary and product information.

This EAO 01-131.025 pushbutton switch is designed for panel mount applications with a front-fitting design. It operates with a 5A current rating at 250V AC and features a DPST-NO/NC circuit configuration.



The switch utilizes solder lug termination for secure connections and offers IP40 ingress protection, making it suitable for various industrial environments. The operating temperature range is from -25°C to 55°C.



Key specifications include a panel cutout dimension of 16.00mm in diameter and a round button actuator type. The series designation is '01', indicating its compact and versatile nature within the EAO product line. Approvals include CB, CSA, ENEC, DNV GL, and UL, along with CE conformity and compliance with LVD and RoHS directives.

01-131.025 Quick Information

Product Type: Pushbutton Switch
Series: 01
Canonical Name: EAO 01-131.025 Pushbutton Switch
Subcategory: Pushbutton

01-131.025 Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

01-131.025 Estimated Pricing

Qty Low High
1+ $0.75 $0.75

Estimated market price range - modelled values for guidance only, not live distributor offers.

01-131.025 Features

  • DPST-NO/NC circuit configuration.
  • Rated for 5A at 250V AC.
  • Solder lug termination style.
  • IP40 ingress protection.
  • Panel mount, front fitting.

01-131.025 Applications

  • Suitable for machinery and automation controls.
  • Ideal for panel building and industrial equipment.
  • Used in safety and indicator switch applications.
  • Applicable in low signal level and high voltage circuits.

01-131.025 FAQs

7 frequently asked questions generated from this part’s specifications.
What is the current and voltage rating for the EAO 01-131.025 pushbutton switch?

The EAO 01-131.025 pushbutton switch is rated for 5A at 250V.

What type of circuit does the EAO 01-131.025 pushbutton switch have?

The EAO 01-131.025 pushbutton switch has a DPST-NO/NC circuit.

What is the operating temperature range for this EAO pushbutton switch?

The operating temperature range for the EAO 01-131.025 pushbutton switch is -25°C to 55°C.

How is the EAO 01-131.025 pushbutton switch mounted?

The EAO 01-131.025 pushbutton switch is designed for panel mount with front fitting.

What is the ingress protection rating of the EAO 01-131.025 pushbutton switch?

The EAO 01-131.025 pushbutton switch has an IP40 ingress protection rating.

What termination style does the EAO 01-131.025 pushbutton switch use?

The EAO 01-131.025 pushbutton switch uses a solder lug termination style.

What are the panel cutout dimensions for the EAO 01-131.025 pushbutton switch?

The panel cutout dimensions for the EAO 01-131.025 pushbutton switch are circular with a 16.00mm diameter.
