| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
627 pcs
|
627 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request | |
|
627 pcs
|
627 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Card Type | |
| Connector Height | |
| Connector Type | |
| Contact Finish | |
| Contact Material | |
| Contact Plating Detail | |
| Current Rating | |
| Durability | |
| Height Above Board | |
| Insertion, Removal Method | |
| Insulator Material | |
| Lead Style | |
| Mounting Feature | |
| Mounting Type | |
| Number of Positions | |
| Operating Temperature Max | |
| Operating Temperature Min | |
| Packaging Type | |
| Sim Installed Height | |
| Standard Package Qty | |
| Tape & Reel | |
| Termination Style | |
| Voltage Rating |
The Kyocera AVX 009162006301150 is a 6-position SIM card connector designed for secure card retention in cellular phones, radios, and other portable devices. It accepts GSM Standard 11.11 cards and features a secure locking latch mechanism for robust resistance against shock and vibration. The connector is polarized to prevent improper insertion.
Electrical specifications include a current rating of 0.3A per contact and a voltage rating of 30VAC. The operating temperature range spans from -55°C to +125°C, making it suitable for harsh environments. Mechanical durability is rated at 10,000 cycles.
The connector is surface mount with a right angle orientation and a hinged lid for easy card insertion and removal. The contact finish is selective gold on the mating surface with tin on solder tails, ensuring reliable conductivity. The insulator is made of high-temperature plastic rated UL94 V-0, and the contact material is copper alloy.
Packaging is tape and reel with 600 pieces per 330mm reel, suitable for automated assembly. The connector height is 2.50mm, and the SIM installed height is 1.50mm.
6 positions.
0.3A per contact.
30VAC.
Surface mount, right angle.
-55°C to +125°C.
Hinged lid.
10,000 cycles.
