006200509130000+ Kyocera AVX 006200509130000+ is a 9-position, 1mm pitch FFC/FPC connector with right angle surface mount, bottom contacts, and slide lock. It features zero insertion force (ZIF) and gold-plated contacts.
Mfr Part #:

006200509130000+

Available from 1 distributors
Mfr Name: Kyocera AVX
Kyocera AVX
Kyocera AVX 006200509130000+ is a 9-position, 1mm pitch FFC/FPC connector with right angle surface mount, bottom contacts, and slide lock. It features zero insertion force (ZIF) and gold-plated contacts.
✓ Total Stock: 2 pcs

006200509130000+ Available from 1 distributor

✓ Authorised
✓ Non-Authorised
Distributor Stock Pricing MOQ PKG Lead Time Date Code On Order Quantity On Order Delivery
Spartce Electronics. ✓
Non-Authorised Inventory information
2 pcs
On Request
2 pcs On Request 1 On Request On Request On Request On Request On Request
DistyParts aggregates offers from multiple distributors. Final prices, lead times and terms are subject to the distributors' discretion and may change without prior notice. DistyParts is not liable for any discrepancies.

006200509130000+ Specifications Quick View

Most important parameters for selection – full specs in datasheet.
Category
Manufacturer Name
Cable End Type
Connector
Connector Type
Contact Finish
Contact Material
FFC, FCB Thickness
Features
Flat Flex Type
Height Above Board
Housing Material
Lead Spacing
Lead Style
Locking Feature
Mounting Type
Number of Positions
Operating Temperature
Pitch
Tape & Reel
Termination
Voltage Rating
View Similar Products (0)

006200509130000+ Description

Short technical summary and product information.

The Kyocera AVX 006200509130000+ is a 9-position FFC/FPC connector from the 6200 series, designed for 1.00mm pitch flat flexible cables. It features a right angle surface mount configuration with bottom contacts, a slide lock for secure cable retention, and zero insertion force (ZIF) actuation for easy cable insertion and removal.



The connector is rated for 50V DC operation and operates over a temperature range of -20°C to 85°C. Contacts are made of copper alloy with gold plating, and the housing is plastic. The connector height above board is 2.90mm, and it accepts FFC/FPC cables with a thickness of 0.30mm.



Packaging is Tape & Reel with a standard quantity of 1000 pieces per reel. The connector is RoHS3 compliant as verified by the manufacturer datasheet.

006200509130000+ Quick Information

Product Type: FFC/FPC Connector Assembly
Series: 6200
Canonical Name: Kyocera AVX 006200509130000+ FFC/FPC Connector, 9 Positions, 1mm Pitch, Right Angle SMT, Bottom Contact, Slide Lock, ZIF
Subcategory: Right Angle SMT Bottom Contact

006200509130000+ Compliance

RoHS Status: RoHS Compliant
Moisture Sensitivity Level (MSL): 1 Unlimited
REACH Status: REACH Unaffected

006200509130000+ Features

  • 9 positions with 1.00mm pitch spacing.
  • Right angle surface mount configuration.
  • Bottom contacts with gold plating.
  • Slide lock for secure cable retention.
  • Zero insertion force (ZIF) design.

006200509130000+ Applications

  • Used in compact consumer electronics devices.
  • Suitable for flat flexible cable interconnects.
  • Ideal for space-constrained PCB layouts.
  • Common in LCD display connections.

006200509130000+ FAQs

7 frequently asked questions generated from this part’s specifications.
How many positions does this connector have?

This connector has 9 positions.

What is the pitch of this FFC/FPC connector?

The pitch is 1.00mm (0.039 inches).

What is the voltage rating of this connector?

The voltage rating is 50V DC.

What mounting type does this connector use?

It uses surface mount, right angle mounting.

What is the operating temperature range?

The operating temperature range is -20°C to 85°C.

Does this connector have a locking feature?

Yes, it has a slide lock for secure cable retention.

What is the contact finish?

The contact finish is gold.
