| Category | |
| Manufacturer Name | |
| Accessory Type | |
| Contact Resistance | |
| For Use With | |
| Insulation Resistance | |
| Mounting Type | |
| Terminal | |
| Termination Style |
The Schurter Inc. 0031.3502 is a shock-safe fuse holder designed for 5x20mm fuse links. It features PCB mounting with solder THT terminals and is suitable for appliances with protection class I.
This fuse holder has a rated voltage of 250 VAC (VDE) or 250 VAC/VDC (UL/CSA) and a rated current of 6.3A (VDE) or 10A (UL/CSA). It offers a degree of protection of IP40 and an admissible ambient temperature range of -40°C to 85°C.
The socket and cap are made from black thermoplastic compliant with UL 94V-0, and the terminals are copper alloy, tin-plated. The unit weight is 4.7g. It is designed according to product standards IEC 60127-6 and UL 4248-1.
This fuse holder is designed for 5 x 20 mm fuse links.
The rated voltage is 250 VAC for VDE and 250 VAC/VDC for UL/CSA.
The rated current is 6.3 A according to VDE and 10 A according to UL/CSA.
This fuse holder is designed for PCB mounting.
The degree of protection is IP40.
The admissible ambient temperature range is -40 °C to 85 °C.
The socket and cap are made of black thermoplastic (UL 94V-0), and the terminals are copper alloy, tin-plated.
