| Distributor | Stock | Pricing | MOQ | PKG | Lead Time | Date Code | On Order Quantity | On Order Delivery | |
|---|---|---|---|---|---|---|---|---|---|
|
68 pcs
|
68 pcs | On Request | 1 | On Request | On Request | On Request | On Request | On Request |
| Category | |
| Manufacturer Name | |
| Connector Type | |
| Contact Finish | |
| Contact Finish Thickness | |
| Contact Length | |
| Contact Material | |
| Contact Shape | |
| Contact Type | |
| Fastening Type | |
| Insulation Color | |
| Insulation Height | |
| Insulation Material | |
| Material Flammability Rating | |
| Mounting Type | |
| Number of Positions | |
| Number of Positions Loaded | |
| Number of Rows | |
| Pitch | |
| SVHC Present | |
| Shrouding | |
| Style | |
| Termination |
The Molex 0026481242 is a 24-position single row header connector designed for board-to-board or cable applications. It features a 3.96mm pitch and right-angle through-hole mounting, making it suitable for space-constrained designs.
This unshrouded header uses tin-plated brass square pins for reliable conductivity and solderability. The black polyester glass-filled insulator is rated UL94 V-0 for flammability resistance. With a push-pull fastening type, it provides secure yet easy mating. The contact length of 14.55mm and insulation height of 3.25mm are designed for robust connections.
Ideal for power and signal interconnections in various electronic assemblies, this connector is RoHS compliant and has an MSL of 1 (unlimited). The right-angle orientation allows for low-profile connections perpendicular to the PCB.
| Qty | Low | High |
|---|---|---|
| 1+ | $0.80 | $1.80 |
| 10+ | $0.55 | $1.30 |
| 100+ | $0.35 | $0.85 |
| 1,000+ | $0.25 | $0.65 |
Estimated market price range - modelled values for guidance only, not live distributor offers.
24 positions in a single row.
3.96mm (0.156").
Through hole, right angle.
Tin, 1.52µm (60.0µin) thickness.
Black glass-filled polyester, UL94 V-0.
Unshrouded.
14.55mm (0.573").
